Product Details
| Model | Thread Size | Stroke (mm) | Max energy absorber (Nm) | Max Impact Speed m/s | ||
|---|---|---|---|---|---|---|
| 1 | 2 | 3 | ||||
| AC0806 | M8 x 1.0 | 6 | 1.8 | 2 | 1.2 | 0.8 |
| AC1005 | M10 x 1.0 | 5 | 3.2 | 2.6 | 1.5 | 0.8 |
| AC1008 | M10 x 1.0 | 8 | 3.2 | 2.6 | 1.5 | 0.8 |
| AC1210 | M12 x 1.0 | 10 | 6 | 2.6 | 1.5 | 0.8 |
| AC1412 | M14 x 1.5 | 12 | 20 | 2.6 | 1.5 | 0.8 |
| AC1415 | M14 x 1.5 | 15 | 20 | 2.6 | 1.5 | 0.8 |
| AC1416 | M14 x 1.5 | 16 | 20 | 2.6 | 1.5 | 0.8 |
| AC2020 | M20 x 1.5 | 20 | 35 | 3.2 | 2 | 1.2 |
| AC2020L | M20 x 1.5 | 20 | 35 | 3.2 | 2 | 1.2 |
| AC2030 | M20 x 1.5 | 30 | 46 | 3.2 | 2 | 1.2 |
| AC2050 | M20 x 1.5 | 50 | 62 | 4.2 | 2.6 | 1.5 |
| AC2525 | M25 x 1.5 | 25 | 78 | 3.2 | 2 | 1.2 |
| AC2540 | M25 x 1.5 | 40 | 122 | 3.5 | 2.2 | 1 |
| AC2580 | M25 x 1.5 | 80 | 198 | 4 | 3 | 1.5 |
| AC3660 | M36 x 1.5 | 60 | 260 | 3 | 2 | 1 |
| ACD2030 | M20 x 1.5 | 30 | 46 | 3.2 | 2 | 1.2 |
| ACD2045 | M20 x 1.5 | 45 | 52 | 3.2 | 2 | 1.2 |
| AD1410 | M14 x 1.5 | 10 | 15 | 3.2 | ||
| AD2016 | M20 x 1.5 | 16 | 28 | 3.2 | ||
| AD2016L | M20 x 1.5 | 16 | 28 | 3.2 | ||
| AD2020 | M20 x 1.5 | 20 | 35 | 3.2 | ||
| AD2020L | M20 x 1.5 | 20 | 35 | 3.2 | ||
| AD2525 | M25 x 1.5 | 25 | 78 | 3.2 | ||
| AD2540 | M25 x 1.5 | 40 | 122 | 3.2 | ||
| AD3650 | M36 x 1.5 | 50 | 220 | 3.2 | ||
| AD4225 | M42 x 1.5 | 25 | 260 | 3.5 | ||
| AD4250 | M42 x 1.5 | 50 | 500 | 4.5 | ||
| AD4275 | M42 x 1.5 | 75 | 750 | 4.5 | ||
| HR30 | 30 | 10-550 | 0.5-30mm/s (load 100kg) |
|||
| HR60 | 60 | 10-550 | 0.5-30mm/s (load 100kg) |
|||
| HR100 | 100 | 10-550 | 0.5-30mm/s (load 100kg) |
|||
